MMA Dual-Cartridge Precision Dispensing Unit
Main functions and benefits
The MMA dispensing unit is designed for precise and efficient dispensing of dual-cartridge fluid materials across a wide range of viscosities. Powered by SERVO/STEP motor technology and utilizing Ball Screw operation, this unit ensures exact fluid control and consistency in every application.
Key Features
- Precise Mixing Ratio Control: Automatically adjusts the mixing ratio to accommodate various fluid volumes, ensuring optimal performance for dual-cartridge materials.
- Advanced Suck-Back Functionality: Prevents dripping caused by residual pressure, maintaining clean, accurate dispensing.
- Wide Viscosity Range: Suitable for handling fluid materials of diverse viscosities with precision.
- Durable and Reliable Design: Engineered for high-performance dispensing in demanding industrial environments.
- 50ml Dual Cartridge 10:1 / 1:1 / 2:1 / 4:1
Product specifications
| Model | MMA |
| Dispensing Speed | Max. 500ml/sec |
| Operation Accuracy | 0.01mm |
| Repeat Accuracy | ±0.02mm |
| Operation Metion | SERVO/STEP |
| Power | AC220V 50-60Hz 250W |
