TAD-500SR is a high-performance conformal coating valve controller designed to regulate both air blow and fluid dispensing in conformal coating applications. This advanced controller features a precise pressure regulator that allows for fine adjustments in the range of 0.001MPa, ensuring accurate fluid and air control for optimal coating performance. The digital display and simple user interface make it easy to set and fine-tune parameters for consistent, high-quality results.

• Precise Pressure Regulation: Offers precise adjustments of 0.001MPa for both air and fluid dispensing, providing accurate control over the coating process.
• User-Friendly Interface: The intuitive digital display and simple interface allow for easy setup and adjustment, ensuring convenience and precision.
• Optimized for Conformal Coating: Specifically designed for controlling conformal coating valves, enhancing accuracy and efficiency in coating applications.
• Enhanced Dispensing Control: Ensures consistent and uniform fluid dispensing, improving the quality of the conformal coating process.

Model	TAD-500SR
Control Method	Electronic / Pneumatic System
Time Range	5bar/20ms
Interval Timer	0.01~99.99 sec
Out Signal	DC24V, 2.5A
Power Source	220V, 1A, 50/60Hz
External Dimension & weight	260(W) x 135(D) x 95(H)mm, 3.0kg
